Automatic Dry Mortar Mixer Machine Ceramic Tile Adhesive Mortar Machine
Product Introduction of Tile Adhensive Mortar Machine:
1. Tile adhesive making machine is based on the latest design concept in Europe, this production adopts the advanced computer auto-control system, whose production capacity can reach 30-100 thousand tons per year depend on the system configuration.
2. The production line consists of storage system, metering and batching system, conveying system, mixing system, air compressor system , packaging system, and dedusting system, etc
3. Mixer for continuous mixing. The finished product in conformity with mixing accuracy requirements can be sent to the finished products bin shortly after mixed.
4. Moreover, there is design with automatic rationing and packaging machine at the bottom of finished products bin, allowing for synchronous auto-packaging operation.
Technical Parameters:
| Model | Full automatic dry mortar plant |
| Output | 10-30t/h |
| Components | cement silo, screw conveyor, automatic weighing system, bucket elevator, premix tank, twin shaft mixer, holding tank, packing machine, automatic control cabinet, air compressor |
| Occupied area | 60-100m2 |
| Total power | 60-120kw |
| Mixer volume | 2m3, 3m3, 4m3 |
| Equipment height | 8-13m |
| Man power | 3-4person |
| Batching and packaging | Automatic batching & Automatic packaging |
Tile adhesive Mixing line work flow:
1. Set weight and proportions of all kinds of raw material , then put the data into the PLC automatic batching system.
2. When the sand is dried, the sand and other raw materials should be put into the storage silo through conveying system.
3. Raw materials in the silo will be delivered to the weightless twin shaft paddle mixer, which is specially designed to meet customers' demands for the fast, precision mixing. The mixer discharges materials quickly and simply, with no difficult to clean dead spots.
4. When the materials are completely mixed, they will be put into the finished silo. Then the finished products should be delivered to the bags. Through the packaging system the bags should be packed.
5. All powdery materials are under the closed state, while feeding, batching, scaling, adding, discharging and packaging. Fully closed mixing unit and the dedusting system can reduce pollution of dust and noise to the environment effectively.
